QR+ Payee Service Provider API (1.0.0)

Version: 1.0.0 (2025-12-04)

Release Candidate 1.0.0-rc-5 approved for publication

Use the Pep 'resolve' endpoint as the starting point of a flow when your customer has scanned a PeP Paylink. The PeSP returns the following information after you have submitted a valid Paylink for resolution:

• Payee identity information which can be presented to the Payer when establishing informed approval.
• Tracking details to facilitate session management and audit traceability.

Use the 'Payment Reply' endpoint to respond to a Payment Request logged to you by the PeSP.

Use the 'Loyalty Reply' endpoint to respond to a Loyalty Request logged to you by the Payee SP.

Use the 'Identity Reply' endpoint to respond to a Identity Request logged to you by the Payee SP.

Flow Session Status Management

• The PrSP is the authority of flow session status. The flow session status can be either OPEN, EXPIRED or TERMINATED with both EXPIRED and TERMINATED being considered closed. The PrSP processes PeSP Requests only while the flow session status is OPEN.
• The PrSP opens a session upon receipt, and successful processing, of either (i) a PrP Paylink resolution request or (ii) a response to a PeP Paylink resolution request. The initial session expiry deadline must be 15s after the session is opened.
• The PrSP may terminate a flow session at will following, for example:
  • A Payer’s request to terminate the session
  • Loss of connectivity to the Payer
  • Processing errors
• The flow session expiry deadline is communicated through an expiresAt timestamp sent by the PrSP to the PeSP in the tracking object of every interaction.
• The PrSP may extend the flow session expiry deadline following, for example:
  • Receipt of an explicit request from the PeSP to do so (through the /request-session-extension endpoint)
  • Additional time required to interact with the Payer
  • A need to resolve ambiguous flow state. (e.g. awaiting a payment conclusion from the PeSP)
• The PrSP must not expire a flow session while there is an outstanding Reply pending to the PeSP and must extend the expiry deadline by at least 5 seconds after making the Reply call to allow the PeSP enough time to process the Reply and optionally send further Requests. The PrSP must make a Reply call to the PeSP for every Request that was accepted irrespective of flow session status.
• When a flow session is TERMINATED or had EXPIRED, the PrSP must return the final flow status with the appropriate error to all subsequent Requests for at least 240 minutes after the final status change. Thereafter the session context may be purged from the system (see Flow Record section for retention requirements).
• The PeSP must use the expiresAt timestamp to manage its activity but must not consider a session closed until formal confirmation to the fact is received from the PrSP.

Recording Flow Interactions

All QR+ Service Providers MUST maintain a record of flow interactions for compliance, traceability, and operational purposes. This record also serves as the foundation for Retry idempotency (see Retry and Idempotency section).

Core Principle: All SP interactions linked to a flow MUST be captured as part of the Flow Record. This includes all ingress payloads (incoming requests and responses) and egress payloads (outgoing requests, responses and replies). All interactions, where a valid flow context exists, MUST be included in a Flow Interaction Record while Interactions (responses) where an Error is returned without a firm flow context being established (e.g. Unauthorized, Forbidden, Flow sequence violations etc.) should not be included .

Structure

When exposing or presenting a Flow Record, its structure must comply to the FlowInteractionRecord schema defined below. This allows consistent formatting by all flow participants and easy comparison of Records between PrSP and PeSP.

const FlowInteractionRecord = z.object({
  payerSpFlowId: PayerSpFlowId,  // Mandatory PrSP Flow ID
  payeeSpFlowId: PayeeSpFlowId,  // Mandatory PeSP Flow ID
  extractedAt: TimeStampRo,  // Instant when record was extracted (flow may still be in progress)
  flowStatus: z.enum(['OPEN', 'EXPIRED', 'TERMINATED']),    // Flow status at instant of extraction
  interactions: z.array(z.discriminatedUnion('reqOrRes', [
    z
      .object({
        reqOrRes: z.literal('REQUEST'), // Request (from Http perspective)
        authCtx: z.object({  // JWT Authorization context
          iss: AuthzAuthorityId,  // JWT issuer
          sub: ServiceId,  // JWT source service (subscriber)
          aud: ServiceId,  // JWT target service (audience)
        }),
        payeeSpMessageSeq: TrackingMessageSeq.optional(), // payeeSpMessageSeq if present in tracking object
        payerSpMessageSeq: TrackingMessageSeq.optional(), // payerSpMessageSeq if present in tracking object
        loggedAt: TimeStamp,
        sourceServiceId: ServiceId,  // The service which was the source of the request
        targetServiceId: ServiceId,  // The service which was the target/destination of the request
        direction: z.enum(['PeSP<=PrSP', 'PeSP=>PrSP']),  // Direction of the request
        payload: z.discriminatedUnion('operation', [  // Any request payload from any Payer or Payee SP API as defined by API schemas
          ...PayeeProviderInteractionRequests.options,
          ...PayerProviderInteractionRequests.options,
        ]),
      })
    z
      .object({
        reqOrRes: z.literal('RESPONSE'), // Response (from Http perspective)
        payeeSpMessageSeq: TrackingMessageSeq.optional(), // payeeSpMessageSeq if present in tracking object
        payerSpMessageSeq: TrackingMessageSeq.optional(), // payerSpMessageSeq if present in tracking object
        loggedAt: TimeStampRo,
        sourceServiceId: ServiceId, // The service which was the source of the response
        targetServiceId: ServiceId, // The service which was the target/destination of the response
        direction: z.enum(['PeSP<=PrSP', 'PeSP=>PrSP']), // Direction of the request
        payload: z.discriminatedUnion('operation', [ // Any response from any Payer or Payee SP API as defined by API schemas (includes http status value)
          ...PayeeProviderInteractionResponses.options,
          ...PayerProviderInteractionResponses.options,
        ]),
      })
  ])),
})

Other Requirements

Flow Interaction Records MUST be retained for at least five years. Flow Interaction Records serve as an audit record and MUST comply to relevant standards and practices.

Retry and Idempotency

QR+ APIs are designed for high-reliability, low-latency server-to-server communication in a distributed peer-to-peer environment. Both PrSP and PeSP implementations must handle transient failures gracefully through Retry mechanisms while preventing duplicate processing through idempotency guarantees.

Client Retries

In the context of this specification, a Retry is defined as an attempt by a client to complete a network exchange that did not receive an official response from the server. This should be seen in contrast to a Re-execute which is an attempt by the client to have the server re-evaluate a previously declined request.

The client, when executing a Retry, MUST use the same tracking sequences it used in the original request. When the intent is to do a Re-execute, it MUST use a different tracking sequence with a value larger than numbers previously used within the Flow context. The server will return a response to a Retry only if the new request is considered equivalent to that originally received. (See server Idempotency requirements)

A client MAY execute a Retry on any timeout condition or Error response but SHOULD limit Retries to errors consistent with communication failures. Retries MUST NOT be captured in in Flow Record to avoid duplicate entries against a specific flow sequence.

Timeout Configuration:

• Clients MUST implement a fixed 3-second timeout for all requests
• This timeout is based on a target p99 latency of less than 1 second across the QR+ ecosystem
• Clients MUST abandon requests that exceed the timeout and treat them as failures eligible for Retry
• Service providers whose services cannot meet the 3-second timeout requirement are considered non-compliant

Circuit Breaker Policy:

• Clients MUST implement circuit breaker protection to prevent cascading failures and enable fast-fail behavior

• Circuit breaker states:

  • Closed (Normal): All requests pass through normally; error rates are tracked continuously
  • Open (Rate-Limited Probing): Requests are rate-limited to one every 3 seconds (2s + random 0-1s); on first successful probe return to closed state; failed probes keep circuit open

• Circuit breaker configuration:

  • Error Rate Threshold: Open circuit when failure rate exceeds 50% over the measurement window
  • Measurement Window: 10 seconds (track success/failure rates over rolling 10-second window)
  • Minimum Request Threshold: 5 requests minimum within window before circuit can open (prevents tripping on sporadic errors under low load)

• When a probe request during open state receives HTTP 503 with a Retry-After header, the circuit breaker SHOULD wait for the indicated duration before the next probe (overriding the 3-second default)

• Circuit breaker state SHOULD be tracked per target service endpoint to isolate failures

• Circuit breaker measurement window stats MUST be cleared when circuit breaker opens to avoid flapping

Retry Strategy:

• Retry logic applies AFTER circuit breaker evaluation (circuit breaker provides first layer of protection)
• Clients SHOULD Retry failed requests immediately (no delay) for the following transient error conditions:
  • HTTP 502 (Bad Gateway) - transient gateway/proxy error
  • HTTP 503 (Service Unavailable) - temporary overload or maintenance
  • HTTP 504 (Gateway Timeout) - upstream timeout
  • HTTP 408 (Request Timeout) - server-side timeout
  • HTTP 429 (Too Many Requests) - rate limiting
  • Network connectivity failures (connection refused, timeout, DNS resolution failure)
• Clients SHOULD NOT Retry for the following permanent error conditions (though servers will handle Retries with Idempotency if they occur):
  • HTTP 400 (Bad Request) - malformed request
  • HTTP 401 (Unauthorized) - authentication failure
  • HTTP 403 (Forbidden) - authorization failure
  • HTTP 404 (Not Found) - resource not found
  • HTTP 422 (Semantic Error) - business rule violation
  • HTTP 500 (Internal Server Error) - non-transient server bug/exception
  • Circuit breaker open errors (do not perform Retries while circuit breaker is open)
• Maximum of 3 Retry attempts per request
• Retries occur immediately after timeout (no backoff delay) - circuit breaker provides cascade protection
• When a 503 or 429 response includes a Retry-After header, clients SHOULD wait for the indicated duration before attempting a Retry

Idempotency for Retries:

• Clients MUST use the tracking mechanism for idempotency rather than introducing additional headers
• When Retrying, clients MUST send an IDENTICAL request body with the same tracking values

Server-Side Idempotency

Servers MUST use the Flow Record as the foundation for Retry idempotency. The Flow Record serves as both a compliance record and a response cache for safe Retry handling. When a request is received which is found to be Equivalent to an interaction on the Flow Record, then the corresponding response on the Record MUST be returned.

Request Equivalence:

Servers determine request equivalence using the following criteria (all must match):

1. Authenticated Identity: Requests with successfully validated JWT where the subject (sub) and audience (aud) claims match. Retries from different issuer or with different keys are allowed to accommodate token expiry
2. Endpoint: The API operation must be identical. The operation is a combination of http path and method
3. Full Request Body: The complete request body (including tracking object) must be identical when compared as canonical JSON

Idempotency Detection and Processing:

When a request arrives, servers MUST:

1. Establish flow context: Authenticate request and retrieve/create flow context
2. Evaluate tracking sequences: Establish whether the request is new (remote message sequence larger than last received). If new, continue with request processing.
3. Retrieve Matching Interaction Record: If the request is not new, retrieve the corresponding Interaction Record from the Flow Record.
4. Evaluate match:
   • No Interaction Record found: This is a flow violation. Return TRACKING:FLOW_SEQUENCE_VIOLATION error response
   • Record found, request bodies match: This is a legitimate Retry. Return response from Interaction Record
   • Record found, request bodies differ: This is NOT a legitimate Retry. Return TRACKING:FLOW_SEQUENCE_VIOLATION

Cached responses must be available for return for a period of 240 minutes after the original request was processed. Sequence violations MUST NOT be logged to the Flow Record because they are request integrity failures, not legitimate Flow Interactions.

Handling Retries During Request Processing:

When a Retry arrives while the original request is still being processed, the Interaction Record entry will exist (request logged) but be incomplete (response not yet logged). In this scenario, servers MUST abandon the request and not send a response. Because the system cannot certify the outcome of the in-flight original request, the fail-safe approach is to trigger a client timeout for future Retry.

Session Expiry Interaction:

• Cached Retries after expiry: Servers MUST continue to return cached responses from the Flow Record for previously processed requests even after session expiry (Flow Record persists beyond session lifetime)
• New requests after expiry: For new requests (not cached Retries) received after session expiry, servers MUST return the appropriate session closure error
• Benefit: Client Retries of in-flight requests during session closure are handled correctly without client needing to track session state.

Server Error Response Guidance:

• Servers SHOULD return HTTP 503 (not 500) for temporary/transient conditions:
  • Service overload or backpressure
  • Downstream service unavailable
  • Maintenance mode
  • Resource exhaustion (connection pool full, queue full, etc.)
• Servers SHOULD include Retry-After header with 503 responses indicating recovery time in seconds
• Use HTTP 500 only for unexpected bugs or exceptions that may not resolve on Retry

Bearer Token Validation

This API uses a JWT based (RFC7519), http bearer token security scheme. The JWT MUST be signed by an authorization authority registered to the QR+ Registry against a Service Provider profile. The API user identity is derived from the JWT issuer, key id and subject claim.

JWT claims

The JWT MUST contain the following Claims:

• iss : Issuer Claim containing the authzAuthorityId as allocated by the QR+ Registry
• sub : Subject Claim containing either:
  • the originating service id when accessing a Paylink enrichment service, or
  • any Service Provider service id when accessing the QR+ Registry.
• aud : Audience Claim containing the service id of the service this token was created to access
• exp : Expiration time Claim defining a time of expiry for this token
• permissions : An array of token permissions for authorizations from:
  • enrich - Can execute enrichment flows against the SP APIs

JWT header

The JWT header must contain the following parameters:

• alg : The JOSE algorithm used for JWT generation
• kid : The key id of the authorization authority key used to generate the JWT

JWT Validation

Implementers of this API must satisfy the following minimum requirements when validating a presented JWT:

• Best Practice: Follow best practices as outlined in RFC8725 and related standards
• User Identity: The API user identity MUST be determined as the service (sub) only when (i) the Issuer claim (iss) matches an Authorization Authority for this service (linked by the Registry) and (ii) The key id of the key used matches a key id used by the authorization authority (kid header parameter)
• Algorithms: JWT MUST fail if the alg property in the header is set to 'none' or if it does not align with the key type of the referenced Authorization Authority
• Audience validation: The service id referenced in the aud Claim MUST match the service id of the service being accessed.

Term	Description
Acceptance Option	A payload specifying a payment rail supported by a Payee for payment. (Option Payload)
Anchor Domain	The common domain used for all Paylink web URIs, allowing deep linking through officially registered mobile applications.
Authorization Authority	An entity, managed on the QR+ Registry, which represents a Service Provider IdP that issues bearer tokens to authenticate API calls. A Service Provider manages Authorization Authorities according to their governance and security policies.
Extended Number Encoded Paylink	A 27-character alphanumeric Paylink format (ZA-FTI-SPII-PLV) optimized for Code128 barcode scanning with extended PLV namespace for medium lifespan experiences.
Facilitated Experience	The experience where the Scanner uses a Paylink Facilitator Application to start a QR+ Flow.
Flow	A Flow is the set of actions executed between a PrSP and PeSP as part of one QR+ session.
Flow Record	An audit trail record, created by both PrSP and PeSP, capturing all Service Provider Interactions exchanged as part of a unique Flow.
Flow Session	A time-bound session that tracks the lifecycle of a Flow with states OPEN, TERMINATED, or EXPIRED. A PrSP only process PeSP Requests while a Flow Session is OPEN.
Flow Tracker	A structured object within Service Provider Interactions containing Flow identifiers and Message Sequence Numbers to coordinate and track messages within a Flow.
Flow Type	A classification of QR+ Flows which govern use case requirements, Paylink lifespan constraints, supported encodings, and security requirements (e.g., pep-general, pep-shortcode, prp-connected, prp-disconnected). Service Providers are licensed for individual Flow Types.
Flow Type Indicator	An encoding-specific identifier that indicates which Flow Type is being used (e.g., 'general' representing the pep-general Flow Type in URI encoded Paylinks and '1' representing the prp-shortcode Flow TYpe in number encoded Paylinks).
Identity Request	A QR+ Request for Payer identity information initiated by the PeSP on behalf of the Payee.
Loyalty Request	A QR+ Request for Payer loyalty membership information initiated by the PeSP on behalf of the Payee.
Message Sequence Number	An incrementing counter maintained by each Service Provider to track the ordering and uniqueness of messages sent within a Flow. Used for audit, idempotency and replay detection.
Number Encoded Paylink	A 13-digit numeric Paylink format (FTI-SPII-PLV-Luhn) optimized for human reproduction via voice or manual keypad entry with built-in error detection.
Payee (actor)	A party who interacts with a Paylink with the intention of receiving payment. The Payee can be either a Scanner or a Presenter depending on the use case.
Payee Service Provider (PeSP)	A registered organization that executes QR+ enrichment flows on behalf of a Payee. The PeSP may deploy Paylink Provider and/or Paylink Facilitator functionality depending on its supported experiences.
Payer (actor)	A party who interacts with a Paylink with intention to pay. The Payer can be either a Scanner or a Presenter depending on the use case.
Payer Service Provider (PrSP)	A registered organization that executes QR+ enrichment flows on behalf of a Payer. The PrSP may deploy Paylink Provider and/or Paylink Facilitator functionality depending on its supported experiences.
Paylink	A structured identifier, encoded and presented in various formats, used by Payers and Payees to initiate a financial interaction.
Paylink actioning	The Scanner scanning the Paylink and submitting it to its Service Provider for processing.
Paylink Encoding Format	A Paylink Encoding Format is a specific way the Paylink attributes are encoded. For example, URI encoded format.
Paylink Facilitator (role)	A PrSP or PeSP organization registered to process Paylinks for Scanners.
Paylink generation	An exchange between the Presenter (Payee or Payer) and the Service Provider (PeSP or PrSP) to generate a new Paylink.
Paylink presentment	The Presenter presenting the Paylink to the Scanner for scanning.
Paylink Presentment Format	A Paylink presentment format specifies the technology used to present the Paylink for scanning. For example, QR code, Barcode and web click.
Paylink Provider (role)	A PrSP or PeSP registered to create Paylinks for Presenters.
Paylink Quarantine Period	The period, after a Paylink has been cancelled, during which the PLV must not be used for a new Paylink.
Paylink resolution	The Paylink Facilitator presenting the Paylink to the Paylink Provider to initiate a QR+ flow.
Paylink Value (PLV)	The cryptographically secure random identifier component within a Paylink that uniquely identifies a specific Paylink instance.
Payment Confirmation	A rail-specific payload passed by the PrSP to the PeSP confirming successful initiation of a Push Payment, without claiming settlement status.
Payment Conclusion	A rail-specific payload passed by the PeSP to the PrSP to provide its view on the outcome of a Payment Request.
Payment Delegation	A rail-specific payload passed by the PrSP to the PeSP containing Pull Payment credentials and transaction details, delegating payment initiation to the PeSP.
Payment Request	A QR+ Request for payment initiated by the PeSP on behalf of the Payee.
Presenter (role)	A Payer or Payee who presents a Paylink to a Scanner party to action. The Presenter interacts with her Service Provider to create the Paylink according to her requirements.
Pull Payment	A payment mechanism that is initiated by a PeSP.
Push Payment	A payment mechanism that is initiated by a PrSP.
QR+ Flow Orchestration	The process of coordinating actions between the PrSP, PeSP, Payer and Payee to achieve a successful transaction outcome.
QR+ Registry Service	A service operated by SARB NPU to enable service discovery of registered Service Providers and Services.
QR+ Service Provider	An organization registered to take part in QR+ flows on behalf of Payers and/or Payees.
Scanner (role)	A party who actions a Paylink by submitting it to their chosen Paylink Facilitator.
Service Provider Indicator	An encoding-specific identifier, assigned by SARB to a registered Service Provider, which allows all Service Providers to identify them as the creator of a Paylink.
Service Provider Interaction	A request and response exchange between a PrSP and a PeSP during a Flow, captured for audit trail, Flow analysis, and idempotency purposes.
Signed CBOR Encoded Paylink	A cryptographically signed Concise Binary Object Representation (CBOR) Paylink format using ECDSA signatures for high-security use cases requiring cryptographic attestation.
URI Encoded Paylink	A non-URL, RFC3986-compliant URI format for Paylinks (qr-plus://<anchor domain>/v1/<flowTypeIndicator>/<spIndicator>/<plv>) supporting deep linking and extended lifespans.
